Quadra-Fire 5700 Step Top Wood Stove

Description

The 5700 Step Top is a wood-burning powerhouse. It’s big on heating performance, and even bigger on efficiency. Automatic Combustion Control (ACC) burn technology offers precision heating control, and easily blends with the Quadra-Fire Four-Point Burn System. Embrace the 5700’s powerful, money-saving, efficient wood stove performance.

- Heat 1,400-3,700 sq ft with 72,100 BTUs*, based on climate and home efficiency
- Low emission levels of 1.8 grams per hour, certified by the EPA
- 3.0 cu ft firebox capacity / recommended 22″ log length
- Up to 15 hours of burn time from each load of fuel†
- Easy start-up
- Also available in these sizes: 4300 Step Top
- KEY TECHNOLOGIES – ACC & 4-point burn system

*The amount of heat produced by a heating appliance is measured in British Thermal Units (BTUs). One BTU represents the amount of energy required to raise the temperature of 1 lb. of water by 1 degree F. Generally, more BTUs correlate to greater heating potential. However, the amount of BTUs needed to heat a specific area varies, based on climate and home efficiency.

Dimensions in inches. Refer to installation/owner’s manual for detailed specifications on installing this product. Hearth & Home Technologies reserves the right to update units periodically. Product installation must adhere strictly to instructions shipped with product.

Model Specifications

5700 Step Top Wood Stove – ACC

Appliance Width	27″
Appliance Height	37-11/16″
Appliance Depth¹	32-3/8″
Fuel Type	Wood
Heating Capacity³	1,400 – 3,700 sq ft
Viewing Area	187 sq in
Efficiency⁵	LHV 80%, HHV 74%
Emissions	1.8 grams/hour

¹ Appliance Depth includes entire unit including depth of firebox and extension onto hearth.

³ This is a general guide, see your local dealer for help in determining the product that best suits your heating needs based on climate, home efficiency, location of the heater, and air movement in the room.

⁵ Weighted average LHV (Low Heating Value) & HHV (High Heating Value) efficiencies using data collected during EPA emissions test. HHV efficiency over 75% qualifies for the Federal Tax Credit.

Heat output will vary depending on the type of fuel used. The flame and ember appearance may vary based on the type of fuel burned and the venting configuration used. Actual product appearance, including flame may differ from image shown. Refer to the owner’s manual for complete clearance requirements and specifications. Product specifications and pricing subject to change without notice. For testing and listing information please refer to the owner’s/installation manual.

*For select products: Heating capacity to be used as a guide only. See your local dealer for help in determining the product that best suits your heating needs based on climate and home efficiency.

5700 Step Top Wood Stove
Base Options

Choose from a pedestal base, cast legs, or Queen Anne legs in two finishes

Satin Nickel Queen Anne Legs	Black Queen Anne Legs	Pedestal Base
Cast Legs

Door Trim Options

The 5700 Step Top provides a choice arched door styles. The arched door comes in classic black or classic black with satin nickel trim. Upgrade your look with optional satin nickel hinge pins and air control handle.
