Quadra-Fire – Excursion Series Gas Fireplace Insert

Category: Tag:

Description

Quadra-Fire gas fireplace inserts turn your drafty inefficient wood fireplace into a beautiful & efficient heat source. With no wood to haul and no mess to clean up, the Excursion Series gas inserts are even easier than you would have ever thought. You will enjoy reliable and fast heat with a powerful fan and efficient steel heat exchange system delivering performance you can feel. With multiple sizes and styles to choose from the Excursion Series will transform you room from the underused to unbelievable in as little as a day.

Excursion Series Gas Fireplace Insert Model Comparison



Model Specifications

Excursion Insert I w/ IFT

Size: 25″
Appliance Width: 26-1/8″
Appliance Height: 17-1/16″
Appliance Depth1: 14-1/2″
Appliance Rear Width: 14-5/8″
Front Width Minimum Firebox Opening: 26-5/8″
Height Minimum Firebox Opening: 17-5/16″
Depth Minimum Firebox Opening: 15″
Back Width Minimum Firebox Opening: 15-1/8″
BTU/hr Input: 27,000
Viewing Area: 22-1/2″ x 12-7/16″
Ignition System: IFT

Excursion Insert II w/ IFT

Size: 30″
Appliance Width: 31-1/8″
Appliance Height: 20-3/4″
Appliance Depth1: 14-1/2″
Appliance Rear Width: 19-5/8″
Front Width Minimum Firebox Opening: 31-5/8″
Height Minimum Firebox Opening: 21″
Depth Minimum Firebox Opening: 15″
Back Width Minimum Firebox Opening: 20-1/8″
BTU/hr Input: 32,700
Viewing Area: 27-1/2″ x 15-15/16″
Ignition System: IFT

Excursion Insert III w/ IFT

Size: 35″
Appliance Width: 36-1/8″
Appliance Height: 24″
Appliance Depth1: 14-1/2″
Appliance Rear Width: 24-5/8″
Front Width Minimum Firebox Opening: 36-5/8″
Height Minimum Firebox Opening: 24-1/4″
Depth Minimum Firebox Opening: 15″
Back Width Minimum Firebox Opening: 25-1/8″
BTU/hr Input: 35,000
Viewing Area: 32-1/2″ x 19-3/8″
Ignition System: IFT

Efficiency

Excursion Insert I w/ IFT

Canada EnerGuide: 68.0%

Excursion Insert II w/ IFT

Canada EnerGuide: 70.9%

Excursion Insert III w/ IFT

Canada EnerGuide: 71.6%

1 Appliance Depth includes entire unit including depth of firebox and extension onto hearth.

Heat output will vary depending on the type of fuel used. The flame and ember appearance may vary based on the type of fuel burned and the venting configuration used. Actual product appearance, including flame may differ from image shown. Refer to the owner’s manual for complete clearance requirements and specifications. Product specifications and pricing subject to change without notice. For testing and listing information please refer to the owner’s/installation manual.

*For select products: Heating capacity to be used as a guide only. See your local dealer for help in determining the product that best suits your heating needs based on climate and home efficiency.
